Bio-Med DevicesFrequently Asked QuestionsHow long will my cylinder last while using the IC-2A?This depends on several factors, but mostly cylinder pressure and tidal volume. The following formula may be used to calculate gas consumption for these ventilators. The result will give you the minutes remaining (or full duration if the cylinder pressure reflects a full cylinder). For a comprehensive sheet to print for your records, click. Cylinder Pressure x Factor (1)Minute Volume + 10 (2) LPM (1) Commonly used factors for cylinders (air or O 2)D-CYL. M-CYL.16.28 2.41 3.14 1.56(2) Average gas consumption of the pneumatic logic circuit in the IC-2A.The IC-2A is considered to be a pediatric through adult ventilator, but not infant. How small a patient can I ventilate using the IC-2A?This is a question best answered by the medical professionals.
The minimum calibrated tidal volume delivered by the IC-2A is 130ml. This could be considered a determining factor.I hear a leak inside my IC-2A even when it is turned off.
Is this normal?A slight bleed is normal with the IC-2A turned off and both gas supplies connected. However, an audible bleed with only a gas source connected to the center logic supply fitting indicates a problem with the supply gas pressure. It is probably below 30 PSI which is below the specification for the ventilator.Why does my ventilator stop cycling when I increase my flow?This is caused by a restriction of some kind in the gas supply to the ventilator. Be sure you are not using a flow regulator to regulate your supply gas. These are too restrictive. They are unable to maintain the necessary pressure with the higher flows. Check for any fittings you may be using before the ventilator that may be restrictive.
Remember, 50 PSI at the wall or cylinder doesn't always mean 50 PSI at the ventilator.Do I need a Service Requisition Form to send a unit in for service?Yes.How close to the MRI unit can I put the IC-2A?First and foremost, the IC-2A must be compatible with a MRI environment. This will be indicated by a 'MRI' plaque on top of the unit and a 'M' at the end of the serial number.
The ventilator should not be placed closer than one meter from the MRI. Click here if you would like a to that effect.How can I monitor for disconnect during a MRI session?You can use a pressure monitor such as our M-1 monitor.
Biomed Devices Ic-2a Service Manual Instructions
It cannot be used in the MRI room, but many hospitals have one set up outside the room with a long tube that tee's into the airway pressure line on the breathing circuit where it connects to the IC-2A. To tee into the circuit, we offer the 8006 tee.
Biomed Devices Ic-2a Service Manual 2016
Bio-Med DevicesFrequently Asked QuestionsHow long will my cylinder last while using the CV4?This depends on several factors, but mostly cylinder pressure and tidal volume. The following formula may be used to calculate gas consumption for these ventilators.
The result will give you the minutes remaining (or full duration if the cylinder pressure reflects a full cylinder). For a comprehensive sheet to print for your records, click. Cylinder Pressure x Factor (1)Minute Volume + 2 (2) LPM (1) Commonly used factors for cylinders (air or O 2)D-CYL.
M-CYL.16.28 2.41 3.14 1.56(2) Average gas consumption of the pneumatic logic circuit in the CV-4.Can I add entrainment to my Crossvent later if I buy it now without?Yes, both the CV3 and CV4 can be upgraded with the entrainment option at any time. We strongly recommend, however, that they be purchased with this option when new as it is much more cost effective.What is the expected life of the battery in the Crossvent?It is recommended that the battery be replaced every two years for optimum performance. The cycle (charge/discharge) life is 500 - 2000 cycles. It is recommended that you leave the charger plugged in when the ventilator is not in use whenever possible.
Also, recharge the battery as soon as possible after using the ventilator in battery mode. To help ensure you get the optimum performance out of your Crossvent's battery, it should be periodically. Click for more information on the Crossvent's battery.Which pneumotach should I buy for my monochrome Crossvent?We offer several pneumotachs, catalog numbers 4407, 4408, and 4409 (CV2 & CV2i only). They are not interchangeable. The 4407 is distinguished by female luer fittings on the ends of its tubes while the 4408 has male luer fittings on the ends of its tubes.
The 4409 has no fittings on the end of its tubes. Check the side of your CV4 to see which fittings you have that will mate with those on the pneumotach. These fittings dictate the matching pneumotach. If your proximal and distal fittings are on the ventilator, then order the 4407. If, then order the 4408. If the fittings are, order the 4409.How should I set the Pressure Cycle function on my CV4?Pressure Cycle is no longer a separate function set by the user. The software has changed to incorporate it into the peak pressure high alarm limit.
It is recommended that if you still have this function in your Crossvent, you send it to to be updated with the latest software enhancements.Why does the blender on my Crossvent leak gas out the bottom?The blender only exhibits this bleed when the knob on the side of the blender is set to 15 LPM and no bleed will be necessary. For a more in-depth explanation of blender bleeds, you can click.Can I replace the Power Supply that comes with the Crossvent with an 'off the shelf' supply?No, this is not recommended.
Any other power supply, other than the one provided by Bio-Med Devices may cause damage and/or unreliable operation. Refer toWhat does it mean to 'refresh' the battery?To refresh the battery means to recondition the rechargeable battery by fully discharging and then recharging it. To do this with the Crossvent, unplug the external power supply, turn the unit on and put it in TEST mode. Press 'VALVES' and turn each valve ON. Leave the unit this way until the display is blank. Turn the Crossvent off, wait at least one minute, then plug the external power supply back in. Charge the battery for a minimum of four hours.Do I need an Service Requisition Form to send a unit in for service?Yes.What are the power requirements for the Crossvent ventilators?When using a desktop plug-in power supply, only the power supply provided by Bio-Med Devices should be used.
Any other power source must comply with the following standards:. Output: 16.0 VDC, 3 A. Output Protection: Short Circuit and Overload. Isolation: Meets IEC601.1, classification BF, UL 544 Patient Care, CSA 125 Risk Class 2G. Maximum Ripple.
